Logix™ 3800zb Digital Positioner FCD AIIOM001030_EN 02/23
flowserve.com 61
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
A
B
C
D
E
F
G
Function
Step
Procedure
Button
I
II
III
Analog
Output
Calibration
(HART)
Initiate calibrations.
Hold I, II and III together for 3
seconds.
3s
3s
3s
Select Analog Output calibration
and allow setting 100%
Press III briefly.
Brief
Adjust output current to 100%
position
Press I or III as needed.
Brief
Brief
Store the 100% value and allow
setting 0%.
Press II to move to the next step.
Brief
Adjust output current to 0%
position.
Press I or III as needed.
Brief
Brief
Complete calibration.
Press II to complete calibration.
Brief
Abort calibration at any time.
Press I, II and III together briefly.
Brief
Brief
Brief
Feedback
Calibration
Initiate low level calibration
functions.
Hold I, II and III together for 6
seconds.
6s
6s
6s
Initiate feedback calibration
function.
Press I briefly. Then rotate feedback
arm all the way around.
Brief
Abort calibration at any time.
Press I, II and III together briefly.
Brief
Brief
Brief
View
Software
Versions
View SW version.
Hold I and II together for 3 seconds.
(Major SW version will be shown.)
3s
3s
View Minor SW version.
Press III briefly.
Brief
View Major SW version.
Press I briefly. (You can toggle back
and forth.)
Brief
Exit viewing SW versions.
Press II briefly.
Brief
Adjust LCD
Screen
Contrast
Enter contrast adjusting mode.
Hold II and III together for 3
seconds.
3s
3s
Select higher contrast.
Press I as needed.
As
Needed
Select lower contrast.
Press III as needed.
As
Needed
Exit contrast adjusting mode.
Press II briefly.
Brief
Remote
Mount
Toggle
Change from RM to Positioner or
back.
Hold I and III together for 6 seconds.
6s
6s
*A full calibration will run if no previous full calibration has been performed since factory reset.
