CHAPTER 3 - OPERATION FLUID COMPONENTS INTL
Table 3-2. Input Power
Table 3-4. Application
FLOW/LEVEL TEMP.
ALARM NO. 1 J20 J21
ALARM NO. 2 J18 J19
JUMPER
POWER SELECT
100-130 VAC 200-260VAC 18-26VAC 21-30VDC
J1 IN OUT OUT OUT
J2 OUT IN OUT OUT
J3 IN OUT OUT OUT
J4 OUT OUT IN OUT
J5 IN IN OUT OUT
J6 OUT IN IN IN
J7 OUT OUT OUT IN
J8 OUT OUT OUT IN
J9 OUT OUT IN OUT
Table 3-5. Relay Energization
Table 3-3A. Selectable Heater Wattage Control
JUMPER J32 J12 J13* J14* J33
FLT93-F ELEMENT
WATTAGE
(560 OHM HTR)
0.57
WATTS
0.52
WATTS
0.49
WATTS
0.20
WATTS
OFF
FLT93-S ELEMENT
WATTAGE
(110 OHM HTR)
3
WATTS
1.75
WATTS
0.75
WATTS
0.27
WATTS
OFF
Table 3-6. Relay Contact Configuration
J UMPER
ALARM NO. 1
J27
RELAY DE-ENERGIZED WITH LOW FLOW, LOW
LEVEL (DRY) OR HIGH TEMPERATURE.
J26
RELAY DE-ENERGIZED WITH HIGH FLOW, HIGH
LEVEL (WET) OR LOW TEMPERATURE
ALARM NO. 2
J25
RELAY DE-ENERGIZED WITH LOW FLOW, LOW
LEVEL (DRY) OR HIGH TEMPERATURE.
J24
RELAY DE-ENERGIZED WITH HIGH FLOW, HIGH
LEVEL (WET) OR LOW TEMPERATURE.
*J13 is standard for FLT93-S and
J14 is standard for FLT93-F.
J23 DUAL SPDT (ONE RELAY PER ALARM)
J22 SINGLE DPDT (DISABLES ALARM NO. 2)
Table 3-3B. Fixed Heater Wattage Control
JUMPER J13 J14 J33
FLT93-F ELEMENT
WATTAGE
(560 OHM HTR)
N.A.
0.20
WATTS
OFF
FLT93-S ELEMENT
WATTAGE
(110 OHM HTR)
0.75
WATTS
N.A. OFF
Numerical Alarm Set Point Adjustment
The control circuit has two mutually exclusive alarms; they are identified as Alarm No. 1 and Alarm No. 2. Each has
an alarm set point adjustment potentiometer and LED indicator. Both alarms can be setup for one of three
applications; flow, level/interface, or temperature. The following application specific adjustment procedures are
generic and can be used for setting either or both alarms. Use Figure 3-2 to help locate the important setup
components (potentiometers, LEDs, etc.).
Doc. No. 06EN003246 Rev. B 3 - 3 FLTÔ Series FlexSwitchÔ
