APPENDIX D - TEMP COMP FLUID COMPONENTS INTL
Table D-2. Temp Comp Factor Table
TEMP TEMP TEMP
COMP R5 R8 COMP R5 R8 COMP R5 R8
FACTOR K OHMS K OHMS FACTOR K OHMS K OHMS FACTOR K OHMS K OHMS
0.042 119.75 263.16 0.013 123.38 149.25 -0.016 127.00 104.17
0.041 119.88 256.41 0.012 123.50 147.06 -0.017 127.13 103.09
0.040 120.00 250.00 0.011 123.63 144.93 -0.018 127.25 102.04
0.039 120.13 243.90 0.010 123.75 142.86 -0.019 127.38 101.01
0.038 120.25 238.10 0.009 123.88 140.85 -0.020 127.50 100.00
0.037 120.38 232.56 0.008 124.00 138.89 -0.021 127.63 99.01
0.036 120.50 227.27 0.007 124.13 136.99 -0.022 127.75 98.04
0.035 120.63 222.22 0.006 124.25 135.14 -0.023 127.88 97.09
0.034 120.75 217.39 0.005 124.38 133.33 -0.024 128.00 96.15
0.033 120.88 212.77 0.004 124.50 131.58 -0.025 128.13 95.24
0.032 121.00 208.33 0.003 124.63 129.87 -0.026 128.25 94.34
0.031 121.13 204.08 0.002 124.75 128.21 -0.027 128.38 93.46
0.030 121.25 200.00
0.001 124.88 126.58 -0.028 128.50 92.59
0.029 121.38 196.08 0.000 125.00 125.00 -0.029 128.63 91.74
0.028 121.50 192.31 -0.001 125.13 123.46 -0.030 128.75 90.91
0.027 121.63 188.68 -0.002 125.25 121.95 -0.031 128.88 90.09
0.026 121.75 185.19 -0.003 125.38 120.48 -0.032 129.00 89.29
0.025 121.88 181.82 -0.004 125.50 119.05 -0.033 129.13 88.50
0.024 122.00 178.57 -0.005 125.63 117.65 -0.034 129.25 87.72
0.023 122.13 175.44 -0.006 125.75 116.28 -0.035 129.38 86.96
0.022 122.25 172.41 -0.007 125.88 114.94 -0.036 129.50 86.21
0.021 122.38 169.49 -0.008 126.00 113.64 -0.037 129.63 85.47
0.020 122.50 166.67 -0.009 126.13 112.36 -0.038 129.75 84.75
0.019 122.63 163.93 -0.010 126.25 111.11 -0.039 129.88 84.03
0.018 122.75 161.29 -0.011 126.38 109.89 -0.040 130.00 83.33
0.017 122.88 158.73 -0.012 126.50 108.70 -0.041 130.13 82.64
0.016 123.00 156.25 -0.013 126.63 107.53 -0.042 130.25 81.97
0.015 123.13
153.85 -0.014 126.75 106.38
0.014 123.25 151.52 -0.015 126.88 105.26
