Appendix E. CE Conformance
Sensing Element
3 4 5 6 7 8
C D E
Approved CE marking FLT Series FlexSwitch Configurations
Approved Options
1) all process temperature ranges
2) all metallic sensor elements
3) all process connections and flanges
4) all insertion U-lengths
5) aluminum and 300 series stainless steel NEMA 4X local and remote enclosures
6) all specified application combinations
7) all cable jackets and lengths
8) 115/230 VAC power input.
Approved Part Numbers
FLT93-S
or
FLT93-F
General
1 2
3
Control Circuit
9 10 11 12 13 14 15
1 or 2
0 A B
C D F
All options conform to CE marking
X Y X or Y options only conform to CE
Requirements.
All other configurations must be approved for CE marking conformity by FCI's Engineering Department.
Conditionally Approved CE marking FLT Series FlexSwitch
Configurations
24 VAC and 24 VDC Field/Factory Selectable Options
Input power of 24 VAC and 24 VDC may be optionally selected. Since the manufacturer does not supply the power
source or transformer for these connections, the responsibility for the conditioning of these sources and associated
compliance to the EMC Directive shall be the responsibility of the User.
Panel Mounted Control Circuit Options
The models included in this family may be supplied with panel mounted (code F block 13 as derived from the above
diagram) control circuit boards. Since the manufacturer does not supply an EMC enclosure for these configurations,
the associated compliance to the EMC Directive shall be the responsibility of the User.
Doc. No. 06EN003246 Rev. B E - 1 FLT Series FlexSwitch
