FLUID COMPONENTS INTL CHAPTER 3 - OPERATION
Table 3-7. Temperature Versus Voltage Output (sheet 1 of 5)
0.00375 OHMS/OHMS/ C 1000 OHMS PLATINUM
°
TEMPERATURE VERSUS VOLTAGE OUTPUT, FLT93
T(°F) V OUT T(°F) V OUT T(°F) V OUT T(°F) V OUT
-100 1.434 -57 1.620 -14 1.804 29 1.987
-99 1.439 -56 1.625 -13 1.809 1.992
-98 1.443 -55 1.629 -12 1.813 31 1.996
-97 1.447 -54 1.633 -11 1.817 32 2.000
-96 1.452 -53 1.637 -10 1.822 33 2.004
-95 1.456 -52 1.642 -9 1.826 34 2.008
-94 1.460 -51 1.646 -8 1.830 2.013
-93 1.465 -50 1.650 -7 1.834 36 2.017
-92 1.469 -49 1.655 -6 1.839 37 2.021
-91 1.473 -48 1.659 -5 1.843 38 2.025
-90 1.478 -47 1.663 -4 1.847 39 2.030
-89 1.482 -46 1.667 -3 1.851 2.034
-88 1.486 -45 1.672 -2 1.856 41 2.038
-87 1.491 -44 1.676 -1 1.860 42 2.042
-86 1.495 -43 1.680 0 1.864 43 2.047
-85 1.499 -42 1.685 1
1.868 44 2.051
-84 1.504 -41 1.689 2 1.873 2.055
-83 1.508 -40 1.693 3 1.877 46 2.059
-82 1.512 -39 1.698 4 1.881 47 2.063
-81 1.517 -38 1.702 5 1.885 48 2.068
-80 1.521 -37 1.706 6 1.890 49 2.072
-79 1.525 -36 1.710 7 1.894 2.076
-78 1.530 -35 1.715 8 1.898 51 2.080
-77 1.534 -34 1.719 9 1.902 52 2.085
-76 1.538 -33 1.723 10 1.907 53 2.089
-75 1.543 -32 1.728 11 1.911 54 2.093
-74 1.547 -31 1.732 12 1.915 2.097
-73 1.551 -30 1.736 13 1.919 56 2.101
-72 1.556 -29 1.740 14 1.924 57 2.106
-71 1.560 -28 1.745 15 1.928 58 2.110
-70 1.564 -27 1.749 16 1.932 59 2.114
-69 1.569 -26 1.753 17 1.936 2.118
-68 1.573 -25 1.757 18 1.941 61
2.122
-67 1.577 -24 1.762 19 1.945 62 2.127
-66 1.581 -23 1.766 20 1.949 63 2.131
-65 1.586 -22 1.770 21 1.953 64 2.135
-64 1.590 -21 1.775 22 1.958 2.139
-63 1.594 -20 1.779 23 1.962 66 2.144
-62 1.599 -19 1.783 24 1.966 67 2.148
-61 1.603 -18 1.787 25 1.970 68 2.152
-60 1.607 -17 1.792 26 1.975 69 2.156
-59 1.612 -16 1.796 27 1.979 2.160
-58 1.616 -15 1.800 28 1.983 71 2.165
