STEP 7: ADJUST HEIGHT OF NEW FILL VALVE
A: TWIST FILL VALVE TO ADJUST HEIGHT
Top of ll valve cap should measure roughly 3”
above top of overow pipe when installed.
TWIST
LEFT
NOTE:
Increasing height allows
more water to ll in the tank.
HOLD
Do Not Move Lock Ring
**
The top of the overow pipe must be a minimum of 1" below tank lever hole.
Fill Valve Cap
Overow Pipe
*Lever Hole
TOP OF FILL VALVE CAP
TOP OF
OVERFLOW PIPE
3"
