STEP 2: REMOVE OLD PARTS
A: REMOVE CONNECTOR
Remove water supply connector from
bottom of ll valve by twisting con-
nector nut to the left.
B: REMOVE OLD LOCKNUT
Use green tool to twist locknut to the
left below tank to remove locknut from
ll valve.
C: REMOVE OLD FILL VALVE
Including rell tube, rell clip and
shank washer. Drain any excess
water into the back panel of
empty packaging by removing ll
valve from tank. (Pull ll valve up)
D: DISCONNECT
FLAPPER CHAIN
Towel
(Optional)
NOTE: Inspect water
supply connector. Replace it if
it is worn, or you don’t know
how old it is, to prevent ooding
and property damage.
Green Tool
Tank Lever
