E: REMOVE TANK FROM BOWL
Use green tool to twist large hex nut to
the left and remove bolts from tank.
G: REMOVE GASKET
Remove tank-to-bowl gasket from
below the tank.
F: LAY TANK ON ITS SIDE
Place on a safe and secure surface.
H: REMOVE FLUSH VALVE
LOCKNUT
Using red wrench, twist locknut left
to remove. Remove old ush valve
from tank.
5
Screwdriver
(Optional)
Red Wrench
Green Tool
NOTE: Bolts can be
loosened from inside tank.
To Next Page
