0000137242 Rev. 7.1 9
3.1.2 GRAPHIC DISPLAY VERSION (DISPLAY 240X128 PIXELS)
The graphic display version is characterized by the following graphic screens and texts.
Main screen:
In this screen are summarized the current status of the measures and the various outputs associated to the relative
measures. It is also displayed the set-point of the relays and the status and time interval of the timed relay R5!
There are also present data on Flow, Current Time, RS485 communication port activation, eventual presence of
alarms, Hold and OFA. Moreover, the eventual appearance of the triangle with the exclamation mark indicates
additional alarms that can be viewed by pressing and holding the ENTER key!
FOR TORBIDITY VERSION:
R5 Time:
Enable
120 s
SP1: 7.23pH
mA1: 12.80 mA
F1: 20p/m
6.90
pH
SP2: 1.19ppm
mA2: 10.72 mA
F2:120p/m
1.50
ppm
SP3: +700mV
+600
mV
SP4: 24°C
25.3
°C
MTC
Flow ON >>HOLD<<
>>OFA<<
15:33
R5 Time:
Enable
120 s
SP1: 7.23pH
mA1: 12.80 mA
F1: 20p/m
6.90
pH
SP2: 1.19ppm
mA2: 10.72 mA
F2:120p/m
1.50
ppm
SP3: +700mV
+600
mV
SP4: 5.00NTU
10.00
NTU
Flow ON >>HOLD<<
>>OFA<<
15:33 25.5°C
