In this mode, by taking advantage of this synoptic table, you will always have an overview of how all the relays are
configured, without having to go into specific sections, and the trend of the measures moment by moment!
All these sections were designed to replicate exactly the structure and the programming mode of the previous
instruments, so that anyone able to program an instrument with alphanumeric display (4x20) can program an
instrument with a graphic display.
In addition, you will always have available the current status of the measures and the programming status of the
various relays.
/---------------------------SetUp-----------------------------\
| 1 Language Uk |
| 2 Calibration |
| 3 Settings |
| 4 Statistics |
| 5 Advanced |
>---------------------------------------------------------------------<
| pH: 7.10 pH Cl: 1.20ppm |
| ORP: +650 mV Temp: 25.5°C |
>---------------------------------------------------------------------<
| R1: 7.23 pH Acid On/Off |
| R2: 1.19 ppm High Timed |
| R3: +700 mV Low PWM |
| R4: 24.0 °C High On/Off |
| R5: Enable 4min 2min |
\
-----------------------------------------------------------------------------------
/
/--------------------------Alarms----------------------------\
| View Alarms |
| Reset Alarms Log |
| Reset Alarm Relay |
| Reset OFA |
| |
>---------------------------------------------------------------------<
| pH: 7.10 pH Cl: 1.20ppm |
| ORP: +650 mV Temp: 25.5°C |
>-------------------------------------------------------------------<
| R1: 7.23 pH Acid On/Off |
| R2: 1.19 ppm High Timed |
| R3: +700 mV Low PWM |
| R4: 24.0 °C High On/Off |
| R5: Enable 4min 2min |
\
-----------------------------------------------------------------------------------
/
/------------------------------Mode------------------------------\
| pH 7.23 pH P:On |
| Cl 1.19 ppm P:Off |
| ORP +700 mV P:Off |
| Temp 24.0°C P:On |
| |
>---------------------------------------------------------------------<
| pH: 7.10 pH Cl: 1.20ppm |
| ORP: +650 mV Temp: 25.5°C |
>------------------------------------------------------------------<
| R1: 7.23 pH Acid On/Off |
| R2: 1.19 ppm High Timed |
| R3: +700 mV Low PWM |
| R4: 24.0 °C High On/Off |
| R5: Enable 4min 2min |
\
-----------------------------------------------------------------------------------
/
