0000137242 Rev. 7.1 30
• Menu index 3B2 Redox (ORP) FREQU OUT
“This menu is available on the pH–Redox System version”
The frequency output (Open collector circuit) can be used to control and guide the dosing of a remote
system in proportion to the Redox measurement.
• Menu index 3B3 Redox OUT Current Output
“This menu is available on the pH–Redox System version”
Note: The value set under the HOLD mA item is automatically generated by the instrument when a functional Hold
is present, for example due to a lack of water Flow Alarm or an enabled Voltage Input.
• Menu index 3B4 Redox ALARMS (level probe alarm only available on pH and Redox systems)
Note: The Holding Range and Holding Time items must be used together.
The indicated function controls the chemical measurement at a constant value for long periods of time.
This alarm can help to prevent incorrect dosing as a result of damaged probes.
Item
Default Value
Range
FWM Standard:
SetPoint:
700 mV
To be verified
Dose
Type
:
Low
High / Low
Pulse
s/minute
:
20
pulses
/minut
e
20
-
150
pulses
/minut
e
Proportional Band:
200 mV
To be verified
Item
Default Value
Range
Standard Out mA:
Range 0/4
-
20mA:
4
-
20 mA
0
-
20 mA o
r
4
-
20 mA
Start (4): 0 p
H
0 mV
Review
End (20): 14 pH
999 mV
Review
Hold Function mA
Value: 0/4 or 20 mA
0 mA
0
-
20 mA
Item
Default Value
Range
pH Alarms List
Alarm minimum:
100 mV
Review
Alarm Maximum:
800 mV
Review
OFA (Maximum dos
e timer):
Off
10
-
3600 Second
s
Holding range:
Off
0.2
-
3 ppm
Holding time:
Off
10
-
3600 Second
s
Level Alarm: System stop or
alarm display
Disable
d
Enable
d
/Disab
le
d
(Available with the pH-Redox
System version)
3B2 FREQU OUT Redox
SET POINT: 700 mV
TYPE DOSE: LOW
PULSE: 20/min
↓
↓↓
↓
3B2 FREQU OUT CHLORINE
TYPE DOSE: LOW ↑
↑↑
↑
PULSE: 20/min
PROP BAND: 200 mV
3B3 mA OUT PH
RANGE: 4-20 mA
START(4): 000 mV
END (20): 999 mV
↓
↓↓
↓
3A3 mA OUT PH
START(4): 0.00ppm ↑
↑↑
↑
END (20): 900 mV
HOLD mA:
20.0 mA
3B4 CHLORINE ALARMS
MIN VAL.: 100 mV
MAX VAL.: 800 mV
H
OLD ALARM: OFF
↓
↓↓
↓
3B4 CHLORINE ALARMS
HOLDING RANGE: OFF ↑
↑↑
↑
HOLDING TIME: OFF
LEV ALARM: DISABLED
