0000137242 Rev. 7.1 31
4.3.4 TEMPERATURE MEASUREMENT SETTINGS MENU (menu index 3D)
Use the UP and DOWN keys to scroll through the various menus and submenus and to modify the data
(increase/decrease).
Use the ENTER key to access the data insertion submenus and to confirm any modifications.
Note: items 3D2 and 3D3 are not available.
The various items contained within the Redox measurement sub-menus are described below:
• Menu index “3C1” TEMPERATURE RELAY
The various items contained within the pH relay’s sub-menus are described below, with their various modes,
ranges and settings:
Item
Default Value
Range
On/Off
:
SetPoint: 25 °C 0-100 °C
Dose Type: High High / Low
Hysteresis: Off 1-20°C
Hysteresis Time: Off 1-900 Seconds
Start Delay: Off 3-900 Seconds
End Delay: Off 3-900 Seconds
Timed
SetPoint: 25 °C 0-100 °C
Dose Type: High High / Low
Hysteresis: Off 1-20°C
Hysteresis Time: Off 1-900 Seconds
Start Delay: Off 3-900 Seconds
End Delay: Off 3-900 Seconds
On
Time
:
1
1
-
1800 Sec
Off Time
:
1
1
-
1800 Sec
Proportional (PWM)
SetPoint: 25 °C 0-100 °C
Dose Type: High High / Low
Hysteresis: Off 1-20°C
Hysteresis Time: Off 1-900 Seconds
Start Delay: Off 3-900 Seconds
End Delay: Off 3-900 Seconds
Period:
20 second
s
20
-
1800
Proportional Band:
6 °C
3
-
30°C
3D TEMPERATURE DOSING
3D1 RELAY ON/OFF
3D2 FMW
3D3 OUTmA
↓
↓↓
↓
3D TEMPERATURE DOSING
3D4 ALARMS ↑
↑↑
↑
3D5 PT TYPE: PT 100
3D6 T.VAL.: 25°C
3D1 RELAY PH
>ON/OFF
TIMED
PWM
The Redox relay’s settings can be varied as follows:
• ON/OFF (SetPoint threshold dosing)
• TIMED (Timed dosing)
• PWM (Proportional dosing)
