fluidra 66178 - Page 34

0000137242 Rev. 7.1 32
3D TEMPERATUR
E DOSING
3D4 ALARMS ↑
↑↑
↑
3D5 PT TYPE: PT 100
3D6 T.VAL.: 25°C
3E Relay Time
Status: Enable
Time On: 5
Time Off:
10
• Menu index “3D4” TEMPERATURE ALARMS
Note: The Holding Range and Holding Time items must be used together.
The indicated function controls the chemical measurement at a constant value for long periods of time.
This alarm can help to prevent incorrect dosing as a result of damaged probes.
Menu index “3D5” Settings
Temperature probe
Use the keyboard to select
the PT100 or PT1000 probe
Menu index “3D6” Settings
Manual temperature value
This menu is available in the absence
of a temperature probe
• Menu index “3E” relais Time
This light activates the Relais output time
between 1 to 999 minutes
Item
Default Value
Range
Temperature Alarms List
Alarm minimum:
15°C
0
-
100°C
Alarm Maximum:
50°C
0
-
100°C
OFA (Maximum Activation Time):
Off
10
-
3600 Seconds
Holding range:
Off
5
-
25 °C
Holding time:
Off
10
-
3600 Seconds
3D4 TEMPERATURE ALARMS
MIN. VAL.: 15°C
MAX. VAL.: 50°C
OFA:
OFF
↓
↓↓
↓
3D4
TEMPERATURE ALARMS
HOLDING RANGE: OFF ↑
↑↑
↑
HOLDING TIME: OFF
