fluidra 66178 - Page 35

0000137242 Rev. 7.1 33
4.3.5 NTU MEASUREMENT SETTINGS MENU (menu index 3F)
Use the UP and DOWN keys to scroll through the various menus and submenus and to modify the data
(increase/decrease).
Use the ENTER key to access the data insertion submenus and to confirm any modifications.
Following describes the various sub-menu items of the NTU measure:
• Menu index “3F1” NTU RELAY
The various items contained within the NTU relay’s sub-menus are described below, with their various modes,
ranges and settings:
• Meu index “3F4” TEMPERATURE ALARMS
Item
Default
value
Range
On/Off
:
SetPoint: 2.00 NTU 0÷10.00 NTU
Dose Type: High High / Low
Hysteresis: Off 1÷3.00NTU
Hysteresis Time: Off 1÷900 Secondi
Start Delay: Off 3÷900 Secondi
End Delay: Off 3÷900 Secondi
Timed
SetPoint: 2.00 NTU 0÷10.00 NTU
Dose Type: High High / Low
Hysteresis: Off 1÷3.00NTU
Hysteresis Time: Off 1÷900 Secondi
Start Delay: Off 3÷900 Secondi
End Delay: Off 3÷900 Secondi
On Time:
1
1÷1800 Sec
Off Time:
1
1÷1800 Sec
Proportional (PWM)
SetPoint: 2.00 NTU 0÷10.00 NTU
Dose Type: High High / Low
Hysteresis: Off 1÷3.00NTU
Hysteresis Time: Off 1÷900 Secondi
Start Delay: Off 3÷900 Secondi
End Delay: Off 3÷900 Secondi
Period:
20 secondi
20÷1800
Proportional Band:
0.3 NTU
3.00 NTU
3F DOSAGGIO TEMPERATURA
3F1 RELAY ON/OFF
3F2 FMW
3
F
3 OUTmA
↓
↓↓
↓
3F DOSAGGIO
NTU
3F4 ALLARMI ↑
↑↑
↑
3F1 RELAY NTU
>ON/OFF
TIMED
PWM
3F4 ALLARMI TEMPERATURA
VAL. MIN: 1.00NTU
VAL. MAX: 5.00NTU
OFA:
OFF
↓
↓↓
↓
3D4
ALLARMI NTU
CAMPO PERM: OFF ↑
↑↑
↑
TEMPO PERM: OFF
The NTU relay’s settings can be varied as follows:
• ON/OFF (SetPoint threshold dosing)
• TIMED (Timed dosing)
• PWM (Proportional dosing)
