Fluidwell E Series

Page 48
FW-E115-P-M_v0203_03_EN.docx
6.4 INTERNAL LABELS.
Label on the main electronics module (MEM):
The labels below are to be found on the main electronics module and supply modules inside the
enclosure.
Labels attached to the Main Electronics Module (MEM) (typical example):
Fig. 29: Example label Main Electronic Module (MEM)
Label attached to the Basic Supply Module (BSM) – option PB.
Fig. 30: Example Label Basic Supply Module (BSM)
Label attached to the Relay Supply Module (RSM) – option (PB)-OR.
Fig. 31: Example Label Relay Supply Module (RSM)
