Runtime variables of the E115-P
Reading flow rate, total, accumulated total or current day totals: When reading runtime variables, the
given value may differ slightly from the value that is displayed on the display – this is due to the fact
that the display is limited in the number of digits and may have a slower update rate.
When variables are read in integer format, the returned values are given including the decimals. For
example, when two decimals are selected for total and total has a value of 123456,78 the display will
show 23456,78 while communication will read a “total” of 12345678 (note that the decimals should
be adapted according the setting in “total decimals” which is in this case 2).
Runtime variables of the E115-P – Integer based – Individual read
PDU
ADDRESS
HOLDING
REGISTER
VARIABLE
NO.
REGISTERS
R/W
TYPE
VALUE / REMARKS
[d] 255
[h] 0x00FF
40256
battery status
1
R
unit16
0 = unknown
1 = normal
2 = low battery
[d] 516
[h] 0x0204
40517
error status (bitfield)
1
R
uint16
[d] 0 = no error
[d] 1 = display error
[d] 2 = data-storage error
[d] 4 = initialization error
[d] 16 = IO configuration error base
[d] 32 = IO configuration error interface
[d] 128 = Automatic K-factor conversion error
[d] 1590
[h] 0x0636
41591
grand total
(differential)
3
R *
uint48
0.000…9999999999
Representation: unit, decimals depending on
variables 32, 33
[d] 1584
[h] 0x0630
41585
grand accumulated
total (differential)
3
R
uint48
0.000…99999999999999
Representation: unit, decimals depending on
variables 32, 33
[d] 1596
[h] 0x063C
41597
grand flow rate
(differential)
2
R
uint32
0.000…9999999
Representation: unit, time, decimals depending
on variables 48, 49, 50
[d] 2272
[h] 0x8E0
42273
grand current day
total
4
R
unit64
0.000…9999999999
Representation: unit, decimals depending on
variables 32, 33
[d] 2280
[h] 0x8E8
42281
grand previous day
total
4
R
uint64
0.000…9999999999
Representation: unit, decimals depending on
variables 32, 33
[d] 566
[h] 0x0236
40567
total A
(forward)
3
R
uint48
0.000…9999999999
Representation: unit, decimals depending on
variables 32, 33
[d] 560
[h] 0x0230
40561
accumulated total A
(forward)
3
R
uint48
0.000…99999999999999
Representation: unit, decimals depending on
variables 32, 33
[d] 572
[h] 0x023C
40573
flow rate A
(forward)
2
R
uint32
0.000…9999999
Representation: unit, time, decimals depending
on variables 48, 49, 50
[d] 1078
[h] 0x0436
41079
total B
(reverse)
3
R
uint48
0.000…9999999999
Representation: unit, decimals depending on
variables 32, 33
[d] 1072
[h] 0x0430
41073
accumulated total B
(reverse)
3
R
uint48
0.000…99999999999999
Representation: unit, decimals depending on
variables 32, 33
[d] 588
[h] 0x024C
40589
flow rate B
(reverse)
2
R
uint32
0.000…9999999
Representation: unit, time, decimals depending
on variables 48, 49, 50
[d] 4640
[h] 0x1220
44641
Total command
register
1
R/W
uint16
Commands:
0x0101: Clear grand total
0x0102: Clear total A
0x0104: Clear total B
0x01FF: Clear all total values
* Clearing total: Total can also be cleared by writing the correct command to the total command register, as shown above.
It is also still possible to use the old method: Write a value of 0 to all the 3 registers of total in a single write action.
Writing any other value will result in the reply of an error message.
Note: The runtime variables shown in above list must always be read or written individually, for the indicated number of
registers, in 1 single action!
