Fluidwell E018 Operation Manual

Page 15
FW-E115-P-M_v0203_03_EN.docx
3.3 CONFIGURATION SETTINGS
All settings of the E115-P can be set via the control panel. As an alternative, you can also use the
Remote Configuration Software which you can find on our website or through your supplier.
Depending on the type of communication interface your device has, you might need a specific
communication cable, which is available through your supplier.
3.3.1 OVERVIEW FUNCTIONS SETUP-LEVEL
1
TOTAL A
1.1
UNIT
L – m3 – US gal – I gal – cf – oil bbl – kg – ton – US ton – lb – (none)
1.2
DECIMALS
0 – 0.1 – 0.02 – 0.003
1.3
K-FACTOR
AUTO, 0.000010 – 9999999
1.4
FACTOR-X
x1 – x10 – x100 – x1000
1.5
CLEAR PASSWORD
000 – 999
1.6
CONTRACT HOUR
00:00 (24h format)
1.7
CURRENT DAY TOTAL
xxxxxxx
1.8
PREVIOUS DAY TOTAL
xxxxxxx
2
FLOWRATE A
2.1
UNIT
mL – L – m3 – mg – g – kg – ton – US ton – US gal – I gal – Oil bbl –
lb – cf – rev – none – scf – nm3 – nL – p
2.2
TIME
/sec – /min – /hour – /day
2.3
DECIMALS
0, 0.1, 0.02, 0.003
2.4
K-FACTOR
AUTO, 0.000010 – 9999999
2.5
CALCULATION
per 1 – 255 pulses
2.6
CUT-OFF
0.1 – 999.9 seconds
3
TOTAL B
3.1
K-FACTOR
AUTO, 0.000010 – 9999999
4
FLOWRATE B
4.1
K-FACTOR
AUTO, 0.000010 – 9999999
5
DISPLAY
5.1
FUNCTION
total – flowrate – acc. total
5.2
DAY TOTALS
off – operate – hidden
5.3
SHOW A-B (acc.total)
enable – disable
5.4
LCD NEW
fast – 1 sec – 3 sec – 15 sec – 30 sec – off
5.5
BACKLIGHT (brightness)
0% – 20% – 40% – 60% – 80% – 100%
5.6
BARGRAPH
disable – absolute – rate a – rate b
5.7
RATESPAN
0000000 – 9999999
6
FLOWMETER
6.1
SIGNAL A
NPN – NPN_LP – REED – REED_LP – PNP – PNP_LP – NAMUR –
Coil_Hi – Coil_Lo – Act_8.2 (8.2V DC) – Act_24 (24V DC)
6.2
SIGNAL B
NPN – NPN_LP – REED – REED_LP – PNP – PNP_LP – NAMUR –
Coil_Hi – Coil_Lo – Act_8.2 (8.2V DC) – Act_24 (24V DC)
6.3
BI-DIRECTIONAL
disable – 90 deg – 270 deg
6.4
CALCULATE
differ – additive – not negative
6.5
K-FACTOR
single – dual
6.6
UNITS
hand – auto-vol – auto-mas
6.7*
UNIT
Auto-vol: L – m3 – US GAL – IGAL – cf – oil bbl
Auto mas: kg – ton – US ton – lb
6.8*
K-FACTOR A
0.000010 – 9999999
6.9*
K-FACTOR B
0.000010 – 9999999
