When Setup 7.1 is set to 1-Step, R2 is used as a scaled pulse output.
The pulse width determines the time that the output will be active; in
output.
The pulse signal always has a 50% duty cycle, hence the minimum
time between the pulses is equal to the pulse width setting. If the
frequency should go out of range when the flow rate increases for
example
It might be that pulses will be missed due to a buffer-overflow, so it is
advised to program this setting within its range!
This setting is used to set the amount of digits behind the decimal point
for the amount.
With Setup 7.1 set at 1-Step, a pulse will be generated on R2 every
time a certain quantity is added to the total chosen with Setup 7.6.
Enter this quantity here while taking the decimals set at Setup 7.4 into
account.
The pulse generation is related to the batch total or the accumulated
total.
new batch is started.
3.3.9 MENU 8 - COMMUNICATION (OPTION)
The F130-P can optionally be equipped with a communication interface using the Modbus protocol
(Type CB/CH/CI/CT). Please consult Appendix C for a more detailed explanation of the protocol,
data types and available registers.
This setting is used to set the baud rate and should match the speed
used on the communications bus.
The following communication speeds can be selected:
1200 2400 4800 9600
This setting is used to configure the bus address of your device on the
communications bus. This address can vary from 001-255.
This setting is used to configure the Modbus communication mode of
your device on the communications bus.
The following modes can be selected: ASCII RTU OFF
For support and maintenance it is important to have information about
the characteristics of the F130-P. Your supplier will ask for this
information in the case of a serious breakdown or to assess the
suitability of your model for upgrade considerations.
All SETUP values can be password protected.
This protection is disabled with value 0000 (zero).
A 4 digit password can be programmed, for example 1234.
For identification of the unit and communication purposes, a unique
tag number of maximum 7 digits can be entered.
