Coil, Switch, PNP, NAMUR
inputs
(terminals 10 and 11,
terminals 13 and 14)
and
Coil, Switch, NPN inputs
(terminals 9 and 10,
terminals 12 and 13)
In type of protection intrinsic safey Ex ia IIB/IIIC or Ex ia IIC, in combination
with connected external supply input type -PD, with following maximum values:
Uo = 8.7 V
Io = 25 mA
Po = 150 mW
Ex ia IIB/IIIC Ex ia IIC
Lo = 210 mH 52.6 mH
Co = 50  5.9 
In type of protection intrinsic safey Ex ia IIB/IIIC or Ex ia IIC, in combination
without connected external supply input type -PD, with following maximum values:
Uo = 5.4 V
Io = 5.2 mA
Po = 7 mW
Ex ia IIB/IIIC Ex ia IIC
Lo = 210 mH 1 H
Co = 50  65 
Active inputs
(Active pulse, 0/4-20mA,
0-10V)
(terminals 9 and 10,
terminals 12 and 13,
terminals 17 and 18,
terminals 17 and 19)
In type of protection intrinsic safey Ex ia IIB/IIIC, only for connection to
a certified intrinsically safe circuit, with following maximum values:
Ui = 30 V
Ii = 100 mA
Pi = 750 mW
Li = 0 mH
Ci = 0 
Pulse/status inputs
(terminals 15 and 16)
In type of protection intrinsic safey Ex ia IIB/IIIC, only for connection to
a certified intrinsically safe circuit, with following maximum values:
Ui = 30 V
Ii = 100 mA
Pi = 750 mW
Li = 0 mH
Ci = 0 
In type of protection intrinsic safey Ex ia IIB/IIIC or Ex ia IIC,
with following maximum values:
Uo = 5.4 V
Io = 1 mA
Po = 2 mW
Lo = 1 H
Co = 65 
PT100 inputs
Type -TP
(terminals 20, 21 and 22,
terminals 23, 24 and 25)
In type of protection intrinsic safey Ex ia IIB/IIIC or Ex ia IIC, in combination
with connected external supply input (type -PX or -PD) or
with connected circuit supply (type -AP), with following maximum values:
Uo = 5.4 V
Io = 162 mA
Po = 750 mW
Ex ia IIB/IIIC Ex ia IIC
Lo = 5.3 mH 1 mH
Co = 1000  65 
In type of protection intrinsic safey Ex ia IIB/IIIC or Ex ia IIC, in combination
without connected external supply input (type -PX and -PD) and
without connected circuit supply (type -AP), with following maximum values:
Uo = 5.4 V
Io = 40 mA
Po = 200 mW
Ex ia IIB/IIIC Ex ia IIC
Lo = 5.3 mH 20 mH
Co = 1000  65 
Data communication circuit
Type -CT
(terminals 26, 27, 28, 29, 30
and 31)
In type of protection intrinsic safey Ex ia IIB/IIIC, only for connection to
a certified intrinsically safe circuit, with following maximum values:
Ui = 30 V
Ii = 250 mA
Pi = 850 mW
Li = 0mH
Ci = 0nF
