Fluidwell F130-P - Page 52

Page 52
FW_F130-P_M_v2201-01_EN.docx
PDU
ADDRESS
REGISTER
VARIABLE
COMMUNICATION
NO.
REGISTERS
R/W
TYPE
VALUE / REMARKS
[d] 144
[h] 0x090
40145
speed (Baudrate)
1
R/W
uint16
0=1200
1=2400
2=4800
3=9600
[d] 145
[h] 0x091
40146
Modbus address
1
R/W
uint16
1…255
[d] 146
[h] 0x092
40147
Modbus mode
1
R/W
uint16
0: ASCII
1: RTU
2: OFF
[d] 147
[h] 0x093
40148
delay
1
R/W
uint16
delay between read and write command
0…65355
[d] 150
[h] 0x096
40151
index
1
R/W
uint16
used for indexed values
[d] 149
[h] 0x095
40150
Index use
1
R/W
uint16
0=
static
1=
increment
2=
decrement
[d] 25
[h] 0x019
40026
reboot
1
R/W
uint16
Returns 0 on read.
Write 0xA50F for unit restart
Write 0x5AF0 for factory settings
PDU
ADDRESS
REGISTER
VARIABLE
OTHERS
NO.
REGISTERS
R/W
TYPE
VALUE / REMARKS
[d] 173
[h] 0x0AD
40174
model number
1
R
uint16
0…9999
[d] 160
[h] 0x0A0
40161
model suffix
1
R
char
Representation: ASCII character
[d] 162
[h] 0x0A2
40163
firmware version
2
R
uint32
0…999999
Representation: nn:nn:nn
[d] 165
[h] 0x0A5
40166
serial number
2
R
uint32
0…9999999
Representation: nnnnnnn
[d] 168
[h] 0x0A8
40169
password
1
R
uint16
0…9999
[d] 170
[h] 0x0AA
40171
tag-nr
2
R/W
uint32
0...9999999
Representation: nnnnnnn
Process variables
PDU
ADDRESS
REGISTER
VARIABLE
NO.
REGISTERS
R/W
TYPE
VALUE / REMARKS
[d] 223
[h] 0x0DF
40224
batch mode
1
R
uint16
Bitfiel[d]
0=idle
1=running
Bitfiel[d]
2=paused
4=finished
Bitfiel[d]
8=in overrun
[d] 154
[h] 0x09A
40155
batch keylock
2
R/W
uint32
0.0…999.9 seconds
[d] 156
[h] 0x09C
40157
batch keylock mask
(keys are not detected)
1
R
uint16
Bitfiel[d]
prog=0x001
Bitfield
start=0x002
Bitfield
stop=0x003
[d] 157
[h] 0x09D
40158
batch command
1
R
uint16
1=start
2=pause
3=stop
4=release
5=reset
Read out returns last
executed command entered
through communication.
Before a new batch can be
initiated through
communication, the release
command must be send. This
way, when combined with the
keylock, overwriting of batch
information (total/preset) data
can be prevented.
[d] 200
[h] 0x0C8
40201
preset quantity
2
R/W
uint32
0…9999999
depending on variable 33: decimals.
