5560A/5550A/5540A
Remote Programmers Manual
46
Table 24. Output Commands
Command Description
CFREQ? Returns the optimum frequency value for stimulus for capacitance modes.
DBMZ Set the impedance used for dBm outputs (ac volts).
DBMZ? Returns the impedance used for dBm outputs (ac volts).
DC_OFFSET Applies a dc offset to an ac output voltage.
DC_OFFSET? Returns the value of the dc offset voltage.
DPF
Set the displacement power factor (phase angle) between the OUTPUT and
AUX terminals for ac power output only.
DPF?
Returns the displacement power factor (phase angle) between the OUTPUT and
AUX terminals.
DUTY Set the duty cycle of square wave outputs.
DUTY? Returns the duty cycle of square wave outputs.
FUNC? Returns the present output, measurement, or calibration function.
HARMONIC
Makes the frequency of one output be a harmonic (multiple) of the other output
(called the fundamental).
HARMONIC? Returns the present instrument harmonic and fundamental locations.
LCOMP_52120
Activates or deactivates inductive load compensation for 52120 ac current
output.
LCOMP_52120?
Returns whether inductive load compensation for 52120 ac current output is
active.
LFREQ? Returns the optimum frequency value for stimulus for inductance modes.
OPER Activates the Calibrator output if it is in standby.
OPER? Returns the operate/standby setting.
OUT
Set the output of the Calibrator and establishes a new reference point for the
error mode.
OUT? Returns the output amplitudes and frequency of the Calibrator.
PHASE
Set the phase difference between the OUTPUT and AUX terminals for dual
outputs. The OUTPUT terminal output is the phase reference.
PHASE? Returns the phase difference between the OUTPUT and AUX terminals.
POWER? Returns the equivalent power for dc and ac power output.
RANGE? Returns the present output ranges.
RANGELCK Locks in the present range, or selects auto ranging.
RANGELCK? Returns whether or not the preset output range is locked.
