Reference Multimeter and 8 ½ Digit Multimeter
SCPI Commands Reference
27
Table 6. Command Summary (cont.)
Keyword Description
[:SENSe]:Frequency
:COUPling AC|DC Sets the frequency path to ac or dc coupled
:COUPling? Returns the coupling setting
:BWLimit[:STATe] <boolean> Sets the bandwidth limit ON or OFF
:BWLimit[:STATe]? Returns the Bandwidth limit setting
:GATE <nrf>|MIN|MAX|DEF
Set gate time to the numeric value in seconds, or to the min,
max or default setting
:GATE? [MIN|MAX|DEF]
Returns the selected gate setting, or if specified, the minimum,
maximum or default gate setting in seconds
:ROUTe:BNC:IMPedance 50R|HIGH Sets the impedance for the rear panel BNC input
:ROUTe: BNC:IMPedance? Returns the impedance set for the rear panel BNC input
:ROUTe: BNC:THReshold
<nrf>|MIN|MAX|DEF
Set Threshold to the numeric value or to the min, max or default
threshold setting (-5.0 V to 5.0 V)
:ROUTe: BNC:THReshold?
[MIN|MAX|DEF]
Return the Threshold numeric value or if specified, the min, max
or default threshold setting
:ROUTe:CURRent:RANGe
<nrf>|MIN|MAX|DEF
Sets the current range to be used if the input path is set to ACI
signal
:ROUTe:CURRent:RANGe?
[MIN|MAX|DEF]
Returns the current range setting
:ROUTe:CURRent:THReshold
<numeric>|MIN|MAX|DEF
Set Threshold to the numeric value or to the min, max or default
threshold setting (-200 % to 200 % of Range)
:ROUTe:CURRent:THReshold?
[MIN|MAX|DEF]
Return the threshold setting
:ROUTe:SIGNal BNC|ACI|ACV Sets the Frequency|Period input path
:ROUTe:SIGNal? Returns the Frequency|Period input path setting
:ROUTe:VOLTage:RANGe
<range>|MIN|MAX|DEF
Sets the voltage range to be used if the input path is set to ACV
signal or to the MIN, MAX, or Default setting
:ROUTe:VOLTage:RANGe?
[MIN|MAX|DEF]
Returns the voltage range setting or the MIN, MAX, or Default
value
:ROUTe:VOLTage:THReshold
<numeric>|MIN|MAX|DEF
Set Threshold to the numeric value or to the min, max or default
threshold setting (-200 % to 200 % of Range)
:ROUTe:VOLTage:THReshold?
[MIN|MAX|DEF]
Return the threshold setting
