8588A/8558A
Remote Programmer's Manual
44
Table 8. SENSe Subsystem Power On and Reset Default Settings (cont.)
Frequency Counter
Gate time: 100 ms
Input Impedance: 50 Ω
Coupling: AC
Bandwidth Limit: OFF
Threshold: 0.0V
Input Path: Rear BNC
DCI Ext Shunt
Range: 1 V
Resolution:0.000001 (6 digits) (min 4 digits, max 7
digits, actual value is range dependent)
Aperture: Auto, (default 1 second, Min 0, Max 10
seconds), NPLC Min = 0 Max = 600
Second reading: OFF
Shunt: Basic Value
Shunt Corrections ON
ACI Ext Shunt
Range: 1 V
Resolution:0.00001 (5 digits) (min 4 digits, max 7
digits, actual value is range dependent)
RMS Filter: 4 0Hz
Signal Path Coupling: AC
Second reading: Shunt Voltage
Frequency path coupling: AC (Disabled)
Frequency path bandwidth limit, OFF
Counter Gate: Auto
Peak to Peak Method: Measured (Disabled)
Shunt Corrections ON
Shunt: Basic Value
RTD, TRTD, FRTD
Probe R0: 100 Ohm
Resolution: Default = 0.1 (5 Digits) Max - 0.01
(6 Digits)
Probe: 2Wire
Units: Celsius
Aperture: Auto, (default 100 ms Min 100 µs, Max 10
seconds)
