Fluke 101 User Manual

Digital Multimeter
Auto Power Off
7
Table 2. Rotary Switch Functions
Number Description Number Description
A Power down the Product.
F
Ohms. Push shift for continuity and
diode test.
B AC Volts G Shift. Push for yellow functions.
C DC Volts H Capacitance
D Freeze the display.
I Frequency. Push shift for duty cycle.
E AC millivolts
Auto Power Off
The Product automatically powers off after 20 minutes of inactivity.
To restart the Product, turn the rotary switch back to the OFF position and then to a
necessary position.
To disable the Auto Power Off function, hold down the YELLOW button when turning on the
Product, until PoFFshows on the display.

Fluke 101 Specifications

General

Display Type	Digital
True RMS	No
DC Voltage Range	0.1 mV to 600 V
AC Voltage Range	0.1 mV to 600 V
DC Current Range	Not available
AC Current Range	Not available
Resistance Range	0.1 Ω to 40 MΩ
Continuity	Yes
Diode Test	Yes
Display	6000 counts
Safety Rating	CAT III 600 V
Battery Type	2 x AAA
Weight	160 g
