Replaceable Parts and Schematics
Warranty and Service Centers
4
4-5
Table 4-1. Final Assembly
REF
DES
DESCRIPTION FLUKE
STOCK
NO
MFRS
SPLY
CODE
MANUFACTURERS
PART NUMBER OR
GENERIC TYPE
TOT
QTY
N
O
T
E
S
BT 1 BATTERY,9V,0-15MA 696534 59717 216 1
H 1-4 SCREW,PH,P,THD FORM,STL,5-14,.750 832246 COMMERCIAL 4
J 3 CONN,ELASTOMERIC,LCD TO PWB,
2.050 L
867247 0K392 867247 1
J 4 CONN,ELASTOMERIC,SWITCH TO
PWB,.500 L
867242 0K392 867242 1
MP 2 CASE,TOP 89536 1 1
MP 3 DECAL,WINDOW 89536 1 2
MP 4 DECAL,CASE TOP 89536 1 3
MP 5 ACTUATOR,SWITCH 879023 89536 879023 1
MP 6 SUPPORT,SWITCH 879031 89536 879031 1
MP 7 SHIELD,TOP (FORMED) 899380 89536 899380 1
MP 8 CASE,BOTTOM 89536 1 4
MP 9 SHIELD,BOTTOM 89536 1 4
MP 10 SHOCK ABSORBER 878983 89536 878983 1
MP 11 FOOT, NON-SKID 885884 89536 885884 1
MP 12 TEST LEADS 855742 89536 855742 1
MP 13 DECAL, WARNING (FOREIGN
LANGUAGE)
897843 89536 897843 1
S 2 SWITCH ASSEMBLY 89536 1 5
TM 1 USERS MANUAL, ENGLISH FLUKE-10 900196 89536 900196 1
TM 2 USERS MANUAL, ENG/INTL, FLUKE-10 900204 89536 900204 1
TM 3 UERSS MANUAL, ENGLISH FLUKE 11/12 900191 89536 900191 1
TM 4 USERS MNL,GER/ITA/JPN,FL-11/12 900209 89536 900209 1
TM 5 USERS MNL,ENG/FRN/SPN,FL-11/12 900212 89536 900212 1
U 3 LCD,3.5 DIGIT,MULTIPLEXED 855226 62786 855226 1
Notes
Y Static sensitive part.
1. FOR FLUKE MODEL 10 ORDER FLUKE STOCK NUMBER 879015
FOR FLUKE MODEL 11 ORDER FLUKE STOCK NUMBER 879010
FOR FLUKE MODEL 12 ORDER FLUKE STOCK NUMBER 879007
2. FOR FLUKE MODEL 10 ORDER FLUKE STOCK NUMBER 890442
FOR FLUKE MODEL 11 ORDER FLUKE STOCK NUMBER 890447
FOR FLUKE MODEL 12 ORDER FLUKE STOCK NUMBER 890343
3. FOR FLUKE MODEL 10 ORDER FLUKE STOCK NUMBER 890467
FOR FLUKE MODEL 11 & 12 ORDER FLUKE STOCK NUMBER 890335
4. ORDER BOTTOM CASE (BOTTOM SHIELD) ASSEMBLY FLUKE STOCK NUMBER 899385.
5. FOR FLUKE MODEL 10 ORDER FLUKE STOCK NUMBER 874730
FOR FLUKE MODEL 11 ORDER FLUKE STOCK NUMBER 874727
FOR FLUKE MODEL 12 ORDER FLUKE STOCK NUMBER 874722
