10, 11, 12 Multimeters
Service Manual
4-8
Table 4-2. A1 Main PCA (cont)
REF
DES
DESCRIPTION
FLUKE
STOCK
NO
MFRS
SPLY
CODE
MANUFACTURERS
PART NUMBER OR
GENERIC TYPE
TOT
QTY
N
O
T
E
S
R 21 RES JUMPER,0.02,0.25W 682575 91637 FRJ-55 1
R 22, 29 Y RES,CERM,300,±5%,.125W,
200PPM,1206
746362 91637 CRCW1206-3000JB 2
R 24 RES,CERM,487K,±1%,.125W,
100PPM,1206
887112 91637 CRCW1206-4873FB 1
R 25 Y RES,CERM,2.2M,±5%,.125W,
200PPM,1206
811778 91637 CRCW1206-2204JB 1
R 26 Y RES,CERM,100K,±1%,.125W,
100PPM,1206
769802 91637 CRCW1206-104FB 1
RT 1 THERMISTOR,POS,1.1K,±20%,25 C 867192 54583 911P67E112MW07 1 2
S 1 SWITCH,SLIDE,3 POSITION,5 PIN 868117 79727 868117 1
U 1 ARTIC, ASSEMBLY TESTED 858472 89536 858472 1
U 2 Y IC,CMOS,4 BIT MPU,LCD
CNTRLR,80PN QFP
866913 33297 UPD75304GF-XXX-3B9 1
VR 1 Y IC, 1.23V,150 PPM T.C.,BANDGAP
V. REF
634451 12040 LM385Z-1.2D26Z 1
XBT 1, 2 CONTACT,BATTERY 897777 89536 897777 2
Y 1 RESONATOR,CERAMIC,PIEZOELEC,
2.10MHZ
876024 54583 FCR2.1MC3 1
Z 1 RES NET THK FILM TESTED 872234 89536 872234 1
Notes
Y Static sensitive part.
1. FOR FLUKE MODEL 10 QTY = 3 C4,11,13
FOR FLUKE MODEL 11 QTY = 3 C4,12,13
FOR FLUKE MODEL 12 QTY = 2 C4,13
2. WARNING - SAFETY RELATED COMPONENTS, USE EXACT REPLACEMENT ONLY.
