Fluke 114 Calibration Information

114, 115, 116, and 117
Calibration Information
10
Table 5. DMM Performance Tests (cont)
Display Reading
Step Function Range Applied
114
[1]
115
[1]
116
[1]
117
[1]
18 6.000V 0V -0.002 to 0.002
19 6.000V 5V 4.973 to 5.027
20 60.00V 50V 49.73 to 50.27
21 600.0V 600V 596.8 to 603.2
22
L
DC Volts
600.0V -600V -596.8 to -603.2
23 600.0 mV 6 mV, 45 Hz 5.6 to 6.4
24
m
AC Millivolts
600.0 mV 600mV, 1 kHz 587.7 to 612.3
25 600.0 mV 10 mV 9.7 to 10.3
26
E
DC Millivolts
600.0 mV 600mV 596.8 to 603.2
27 G Diode 2.000 V 1.9V
N/A 1.881 to 1.919
28 1000 nF Open
N/A 0 to 2 0 to 2 0 to 2
29
E
Capacitance
9999 μF 900 μF N/A 881 to 919 881 to 919 881 to 919
30 LoZ
Capacitance
10.00 μF 9 μF N/A 7.18 to 10.82
Set calibrator to standby, reconfigure leads, and program for amps output
31 A
DC Amps
10.00 A 10A N/A
9.87 to
10.13
N/A
9.87 to
10.13
32 ?
AC Amps
6.000 A 5.0A, 45 Hz N/A
4.922 to
5.078
N/A
4.922 to
5.078
33 $
DC μamps
600.0 μA 600 μADC N/A N/A
593.8 to
606.2
N/A
34 $
AC μamps
600.0 μA 600 μAAC, 45 Hz N/A N/A
590.7 to
609.3
N/A
35 Open input N/A N/A 0PEn N/A
36 0.0 °C N/A N/A -1.0 to 1.0 N/A
37
y
Temperature
400 °C N/A N/A
395.0 to
405.0
N/A
38 0.5 V, 45 Hz 0.2 to 0.8,
AC
Annunciator
On
N/A
0.2 to 0.8,
AC
Annunciator
On
0.2 to 0.8,
AC
Annunciator
On
39 0.5 V, 0 Hz 0.2 to 0.8,
DC
Annunciator
On
N/A
0.2 to 0.8,
DC
Annunciator
On
0.2 to 0.8,
DC
Annunciator
On
40
x
500 V
[2]
,
500 Hz
489.7 to
510.3
N/A
489.7 to
510.3
489.7 to
510.3

Fluke 114 Specifications

General

Frequency range	0.005 - 50 kHz
Continuity check	Yes
DC voltage range	0.0001 - 600 V
Resistance range	1 - 600 Ω
Resistance resolution	1 Ω
Resolution (DC voltage)	0.0001 mV
Basic accuracy (DC voltage)	1.0% + 3 (DC, 45 Hz to 500 Hz)
Temperature measurement range	-40 - 400 °C
Battery type	9V
Battery voltage	9 V
Number of batteries supported	1

Weight and Dimensions

Depth	46 mm
Width	84 mm
Height	167 mm
Weight	550 g
