Fluke 12 Service Manual

10, 11, 12 Multimeters
Service Manual
3-8
Table 3-2. Performance Tests for Fluke 10
Test No. Meter Range Input To Meter Slide-Switch
Position
Display
Minimum
Display
Maximum
1 4.000V AC 0V Center 0.000 0.003
2 4.000 AC 10 mV, 50 Hz Center 0.007 0.013
3 4.000 AC 10 mV, 400 Hz Center 0.007 0.013
4 4.000 AC 3.5V, 50 Hz Center 3.395 3.605
5 4.000 AC 3.5V, 400 Hz Center 3.395 3.605
6 40.00V AC 35V, 50 Hz Center 33.95 36.05
7 40.00V AC 35V,400 Hz Center 33.95 36.05
8 400.0V AC 350V, 80Hz Center 339.5 360.5
9 600V AC 600V, 400Hz Center 580 620
10 4.000V DC 0V Center 0.002 0.002
11 40.00V DC +20 mV DC Center 00.01 00.03
12 400.0V DC -200 mV DC Center -000.3 -000.1
13 4.000V DC +3.5V Center +3.445 +3.555
14 40.00V DC -35V DC Center -35.54 -34.46
15 400.0V DC +100V DC Center +98.4 +101.6
16 600V DC -600V DC Center -610 -590
17 Continuity +2V DC Right 1.968 2.032
18 400.0Ω 0.0Ω Right 0.0 0.2
19 400.0Ω 1.0Ω Right 0.8 1.2
20 400.0Ω 350.0Ω Right 344.5 355.5
21 4.000 kΩ 1.0 kΩ Right 0.984 1.016
22 40.00 kΩ 35 kΩ Right 34.46 35.54
23 400.0 kΩ 100 kΩ Right 98.4 101.6
24 4.000 MΩ 2.9 MΩ Right 2.855 2.945
25 40.00 MΩ 35 MΩ Right 34.30 35.70

Fluke 12 Specifications

General

Continuity Beeper	Yes
Diode Test	Yes
Safety Rating	CAT III 600 V
Operating Temperature	0 °C to 50 °C
Display Type	LCD
Voltage DC	600V
Voltage AC	600V
DC Current Range	10 A
AC Current Range	10 A
Resistance Range	40 MΩ
Battery Type	9V
Dimensions	169 mm x 84 mm x 44 mm
