Fluke 12 Service Manual

Maintenance
Calibration
3
3-9
Table 3-3. Performance Tests for Fluke 11 and 12
Test
No.
Meter Range Input To
Meter
Slide-Switch
Position
Display
Minimum
Display
Maximum
1 4.000V AC 0V Center 0.000 0.003
2 4.000V AC,MIN MAX* 0V Center 0.000 0.040
3 4.000V AC 10 mV, 50 Hz Center 0.007 0.013
4 4.000V AC 10 mV, 400 Hz Right 0.007 0.013
5 4.000V AC 3.5V, 50 Hz Right 3.430 3.570
6 4.000V AC 3.5V, 400 Hz Center 3.430 3.570
7 40.00V AC 35V, 50 Hz Center 34.30 35.70
8 40.00V AC 35V, 400 Hz Right 34.30 35.70
9††† 400.0V AC 350V, 80 Hz Right 343.0 357.0
10 600V AC 600V, 400 Hz Center 586 614
11 4.000V DC,MIN MAX* 0V Center -0.012 0.012
12 4.000V DC 0V Right -0.002 0.002
13 40.00V DC +20 mV DC Right 00.01 00.03
14 400.0V DC -200mV DC Center -000.3 -000.1
15 4.000V DC +3.5V Center +3.466 +3.534
16 40.00V DC -35V DC Center -35.33 -34.67
17 400.0V DC +100V DC Center +99.0 +101.0
18 600V DC -600V DC Center -606 -594
19 Continuity +2V DC** Right 1.980 2.020
20 Continuity, VCHEK +3.43V DC** Right 3.397† 3.463†
21 Continuity, VCHEK -0.5V DC** Right -0.507† -0.493†
22 400.0Ω 0.0Ω Right 0.0 0.2
23 400.0Ω 1.0Ω Right 0.8 1.2
24 400.0Ω 350.0Ω Right 346.6 353.4
25 4.000 kΩ 1.0 kΩ Right 0.990 1.010
26 40.00 kΩ 35 kΩ Right 34.67 35.33
27 400.0 kΩ 100 kΩ Right 99.0 101.0
28 4.000 MΩ 2.9 MΩ Right 2.873 2.927
29 40.00 MΩ 35 MΩ Right 34.44 35.56
30 Ω, VCHEK 1.96V DC Right 1.940† 1.980†
31†† 1.000µF0.0µF Right -0.001µF 0.001µF
32†† 1.000µF0.95µF Right 0.93µF 0.970µF
* MIN MAX tests are for Fluke 12 only.
** Calibrator 50Ω divider override.
† The dc volts annunciator must be on.
†† Conducting performance tests of the 400Ω, 4 kΩ, 40 kΩ, and 1 µF ranges (tests no. 22, 23, 24,
25, 26, 31, and 32) verifies that the discrete and integrated circuitry needed to support the other
capacitance ranges are working within specifications. Therefore, these tests indirectly verify that the
meter will meet specification in the 10 µF, 100 µF, 1000 µF, and 10,000 µF ranges.
††† In the V-CHEK mode, the UUT uses a low-impedance thermistor (approx. 2.5 kΩ) for circuit
protection and load testing (referred to as lo-Z input circuitry). When using the 5100B or 5700A to drive
the UUT with higher voltages, avoid an overload/current limit condition by gradually stepping the voltage
up (waiting two seconds between each step) from 90.0V, 120.0V, 180.0V and 350.0V at 80 Hz each step.

Fluke 12 Specifications

General

Continuity Beeper	Yes
Diode Test	Yes
Safety Rating	CAT III 600 V
Operating Temperature	0 °C to 50 °C
Display Type	LCD
Voltage DC	600V
Voltage AC	600V
DC Current Range	10 A
AC Current Range	10 A
Resistance Range	40 MΩ
Battery Type	9V
Dimensions	169 mm x 84 mm x 44 mm
