Replaceable Parts and Schematics
Introduction
4
4-3
4-1. Introduction
This section contains an illustrated list of replaceable parts and a schematic drawing for
Series 10 Multimeters. Parts are listed by assembly; alphabetized by reference
designator. Parts unique to a specific model are identified. Each assembly is
accompanied by an illustration showing the location of each part and its reference
designator. The parts lists give the following information:
Reference designator
An indication if the part is subject to damage by static discharge
Description
Fluke stock number
Manufacturers supply code for manufacturers. (code-to-name list at end
of this section)
Manufacturers’ part number or generic type
Total quantity
Any special notes (i.e., factory-selected part)
Manufacturers part number or generic type
Total quantity
Any special notes (i.e., factory-selected part)
CAUTION
A Y symbol indicates a device that may be damaged by static
discharge.
4-2. How To Obtain Parts
Electrical components may be ordered directly from the manufacturer by using the
manufacturers part number, or from the John Fluke Mfg. co., Inc. and its authorized
representatives by using the part number under the heading FLUKE STOCK NO. In the
U.S. order directly from the Fluke Parts Dept. by calling 1-800-526-4731. Parts price
information is available from the John Fluke Mfg. Co., Inc or its representatives. Prices
are also available in a Fluke Replacement Parts Catalog which is available on request.
In the event that the part ordered has been replaced by a now or improved part, the
replacement will be accompanied by an explanatory note and installation instructions, if
necessary.
To ensure prompt delivery of the correct part, include the following information when
you place an order:
Instrument model and serial number
Description (as given under the DESCRIPTION heading)
Quantity
Reference designator
Part number and revision level of the pca containing the part.
Fluke stock number
4-3. Schematics
Figures 4-3 through 4-5 are schematics of the Series 10 Multimeters.
