Fluke 12 Service Manual

Replaceable Parts and Schematics
Warranty and Service Centers
4
4-7
Table 4-2. A1 Main PCA
REF
DES
DESCRIPTION
FLUKE
STOCK
NO
MFRS
SPLY
CODE
MANUFACTURERS
PART NUMBER OR
GENERIC TYPE
TOT
QTY
N
O
T
E
S
C 1 CAP,TA,0.47UF,±20%,35V 655035 56289 199D474X0035AG2 1
C 2, 5-7 CAP,POLYES,0.022UF,±10%,50V 715268 37942 37942 185-2-223K50AA 4
C 3 CAP,TA,22UF,±20%,6V,6032 876545 56289 293D226X06R3C2T 1
C 4, 11,
13
CAP,CER,0.1UF,±10%,25V,X7R,1206 747287 04222 12063C104KAT060B 1
C 8 CAP,TA,3.3UF,±20%,16V,3528 876552 56289 293D335X0016B2T 1
C 9 CAP,CER,0.022UF,±10%,50V,X7R,
1206
747279 04222 12065C223KAT060B 1
C 10 CAP,AL,22UF,±20%,10V,SOLV
PROOF
887245 62643 KRG10VB22RM4X7RP 1
C 14 CAP,POLYES,0.01UF,±10%,1000V 822361 68919 MKS4.01/1000V/10 1 2
C 15 CAP,TA,47UF,±20%,10V,7343 867580 89536 867580 1
C 16 CAP,CER,10PF,±20%,50V,C0G 721589 04222 SR595A100MAA 1
CR 1 DIODE,SI,100 PIV,1.0 AMP 912451 04713 1N4002 1
CR 2 Y DIODE,SI,DUAL,BV=50V,
IO=100MA,SOT23
851659 04713 MBAV74T1 1
CR 3 Y DIODE,SI,BV=70.0V,
IO=50MA,DUAL,SOT23
742320 8A233 BAV99 1
E 1 SURGE PROTECTOR,3750V,±20% 867361 91984 91984 100-HT1 1
J 1, 2 RECEPTACLE,INPUT 878988 89536 878988 2
LS 1 AF TRANSD,PIEZO,20MM 876995 59096 59096 KBS-20DB-2T-5 1
Q 1 Y TRANSISTOR,SI,NPN,SELECT
IEBO,SOT-23
821637 04713 SMBT1388LT1 1
Q 2 Y TRANSISTOR,SI,PNP, SELECT
ICER,SOT-23
887179 04713 SMBT1531LT1 1
R 1 Y RES,CERM,162K,±1%,.125W,
100PPM,1206
876198 91637 CRCW1206-1623FB 1 2
R 2 RES,MF,332K,±1%,0.125W,100PPM 655217 59124 MF50D3323F 1
R 3 RES,MF,23.4K,±0.1%,0.125W,
100PPM
876292 59124 MF50D2342B 1
R 4 RES,VAR,CERM,25K,±25%,0.2W 876300 80294 80294 3306P-1-253 1
R 5 RES,CERM,43.2K,±1%,.125W,
100PPM,1206
887109 91637 CRCW1206-4322FB 1
R 6 Y RES,CERM,226K,±1%,.125W,
100PPM,1206
876524 91637 CRCW1206-2263FB 1
R 7-9,
23, R 28
Y RES,CERM,1M,±1%,.125W,
100PPM,1206
836387 91637 CRCW1206-1004FB 5
R 10 Y RES,CERM,309K,±1%,.125W,
100PPM,1206
876201 91637 CRCW1206-3093FB 1
R 11, 12 RES,MF,30.1K,±0.1%,0.125W,
100PPM
887161 59124 MF50D3012B 2
R 13 RES,MF,27.1K,±0.1%,0.125W,100PPM 876289 59124 MF50D2712B 1
R 14, 15 Y RES,CERM,10K,±5%,.125W,
200PPM,1206
746610 91637 CRCW1206-1002JB 2
R 16, 18 Y RES,CERM,470,±5%,3W, 100PPM 887117 23237 GS-3-470-5% 2 2
R 17 Y RES,CERM,1M,±5%,1W 655175 19647 MS214-105-5%-
200PPM/C
12
R 19 RES,MF,500,+0,-20%,
100PPM,FLMPRF,FUS
887034 91637 91637 CMF-65 89-4500K
T-1
12
R 20, 27 Y RES,CERM,0,+.05 MAX,.125W,1206 810747 91637 CRCW1206-0R00B 2 2

Fluke 12 Specifications

General

Continuity Beeper	Yes
Diode Test	Yes
Safety Rating	CAT III 600 V
Operating Temperature	0 °C to 50 °C
Display Type	LCD
Voltage DC	600V
Voltage AC	600V
DC Current Range	10 A
AC Current Range	10 A
Resistance Range	40 MΩ
Battery Type	9V
Dimensions	169 mm x 84 mm x 44 mm
