10, 11, 12 Multimeters
Service Manual
4-6
MP3
MP2
J3
U3
J4
MP7
MP6
A1
MP10
BT1
MP8
H1-4
MP11
MP7
MP9
MP5
S2
MP4
ana05f.eps
Figure 4-1. Final Assembly Drawing
