Using the Meter
Connecting to the Circuit Under Test
Figure 3 shows the proper connections.
W
Warning
To prevent electric shock when performing resistance tests, remove all
power from the circuit to be measured.
W
Warning
To prevent electric shock, first connect the test leads to the Meter inputs
before you make connection to the circuit under test.
