Fluke 1520 User Manual

Fluke 1520
Users Manual
16
Measuring Low Resistance
To measure low resistance:
1. Zero out the test lead resistance (see Table 1).
2. Connect the probes to the circuit to be measured.
If voltage is present on the probes, the voltage is displayed.
W
Warning
A repetitive beep and the flashing high voltage
symbol (
Y
) warn the user if voltage more than 30 V ac
or dc is present. If the voltage is > 30 V ac or dc,
remove the voltage from the circuit under test before
proceeding with the next step.
acf06f.eps
3. Press and hold the TEST button. A single beep indicates a stable reading. The
resistance shows on the main display. If the resistance is higher than 40 Ω, >40 Ω is
displayed.
4. Release the TEST button. The upper right display holds the resistance reading until a
new test is started or a different function is selected.
