Fluke 1520 - Page 36

MegOhmMeter
Specifications
31
Electrical Specifications
Battery C Size 1.5 V alkaline, ANSI/NEDA-14A, IEC-
LR14 (4 pieces)
Fuse 6 mm x 32 mm (0.25 x 1.25 inch), 0.5 A 660 V,
Fast Acting, 50 A Minimum Interrupt rating
Insulation Resistance
Display Ranges 4.000 MΩ, 40.00 MΩ, 400.0 MΩ, 4000 MΩ
Measurement Range (per EN61557-2) 0.250 MΩ to 4000 MΩ
Resolution 0.001 MΩ to 10 MΩ
2 % + 2 counts
0.250 MΩ to 100.0 MΩ
Accuracy
10 % + 2 counts + 1 %/1000 MΩ
100.0 MΩ to 4000 MΩ
Analog Bar Graph 0 to ∞
