15B MAX/17B MAX
Users Manual
14
Service and Parts
If the Product fails:
1. Make sure the batteries are charged.
2. Test the fuses.
3. Review this manual to make sure that you correctly
operate the Product.
Replacement parts are listed in Ta b le 1 .
TL31 Test Leads
XWWarning
To prevent possible electrical shock, fire or
personal injury:
Do not use test leads if they are damaged.
Examine the test leads for damaged insulation,
exposed metal, or if the wear indicator shows.
Check test lead continuity.
Use the test leads with caution and install the
protective cap to prevent injury.
The TL31 Test Leads that come with the Product 15B MAX-
02, 15B MAX KIT, 17B MAX-02, and 17B MAX KIT have fine
tips to test small components of the circuit. With the
protective cap properly installed, use the leads for CAT III
applications.
Table 1. Replacement Parts
Item Description Part No.
Battery, IEC LR6 376756
Battery door assembly 5338510
TL31, test leads with two caps and fine tips 5343862
TL75, test leads with two caps 4306653
Fuse, 0.440 A, 1000 V, FAST 943121
Fuse, 11 A, 1000 V, FAST 803293
Holster 4368113
