Connector Panel Decal
A self-adhesive decal is supplied with the Logger. The decal
corresponds to the wiring color codes used in your local area of
operation. Apply the decal around the current and voltage inputs on
the connector panel as shown in Table 6.
Table 6. Decal for Connector Panel
Item Location Part Number

USA 4772711

Europe 4772884

Canada 4772727

UK (old standard) 4772730

China 4772748
CURRENT
INPUTS
CURRENT
INPUTS
CURRENT
INPUTS
CURRENT
INPUTS
CURRENT
INPUTS
CURRENT
INPUTS
1
2
3
4
5
