15B MAX/17B MAX
Calibration Manual
10
8. When you complete adjustment, turn off the DUT.
Figure 7. Temperature Adjustment 17B MAX
Table 5. All Function Adjustments
Function Step Display
15B
MAX
17B
MAX
Calibrator Output
VAC 1
High voltage mark (
Y) flickers
√√3 V, 50 Hz
VDC 1
High voltage mark (
Y) flickers
√√3 V, 0 Hz
Cap 1
High voltage mark (
Y) flickers
√√
100
μF
ADC 1
High voltage mark (
Y) flickers
√√3A, 0 Hz
mADC 1
High voltage mark (
Y) flickers
√√30 mA, 0 Hz
Te m p e r a t u r e 1 Te m p e r a t u r e X √
0
°C
