15B & 17B
Calibration Manual
4
General Specifications
Maximum Voltage between any
Terminal and Earth Ground: 1000 V
W Fuse Protection for mA µA inputs: 500 mA, 1000 V FAST, Min. Interrupt Rating 20,000 A
W Fuse Protection for A input: 10 A, 1000 V FAST, Min. Interrupt Rating 20,000 A
Display: Digital: 4000 count updates 3/sec
Temperature: Operating: 0 °C to 40 °C, Storage: -30 °C to 60 °C
indefinitely (to -40 °C for 100 hours)
Operating Altitude: 0 to 2000 meters
Temperature Coefficient: 0.1 X (specified accuracy)/ °C (<18 °C or >28 °C)
Electromagnetic Compatibility: Complies with FCC Part 15, Class B, IEC 61326, 3 V/m,
performance criterion B
Rated Transient Overvoltage: 4 kV (1.2 x 50 µs) Peak for measurement Categories I, II,
and III.
Relative Humidity: Noncondensing < 10 °C
90% from 10 °C to 30 °C; 75% from 30 °C to 40 °C
Relative Humidity, 40 MΩ Range: 80% from 10 °C to 30 °C; 70% from 30 °C to 40 °C
Battery Type: 2 X AA, NEDA 15A, IEC LR6
Battery Life: Alkaline: 500 Hours
Size (H x W x L): 180 mm x 89 mm x 51.5 mm (with holster)
Weight: 425 grams
Certifications: CMC, P
Safety Compliance: IEC 61010-1, 2000 CAT I 1000 V, CAT II 600 V, and CAT III
300 V overvoltage standards
Overvoltage installation categories per IEC 61010-1, 2000: The Meter is designed to protect against
transients in these catagories:
CAT I: From high-voltage low-energy sources, e.g., electronic circuits or a copy machine.
CAT II: From equipment supplied from the fixed installation, e.g., Televisions, PCs, portable tools and
household appliances.
CAT III: From equipment in fixed equipment installations, e.g., installation panels, feeders and short
branch circuits, and lighting systems in large buildings.
