Model 16 English Instruction Sheet
Page
11
Disabling the Beeper
To disable the beeper for all modes, hold down r for 2 seconds while
turning the meter on.
Continuity Capture
To set up the meter to capture intermittent shorts and opens, turn the
switch to
GR, connect the leads to the circuit; then press M .
ip12i.eps
Captures transitions longer than 250 µs (1/4000
th
of a second).
Transitions after the first transition cause the meter to beep, but the
display does not change.
To reset the display to the current condition, press
M.
To exit, press M for 2 seconds, or change the measurement mode.
