Model 16 English Instruction Sheet
Page
2
Symbols
Press button.
Press button to switch between modes.
Double insulation.
Manual ranging mode.
ip14i.eps
Automatic Range Selection
The meter defaults to autoranging when you turn it on. The 4000 mV
range can be entered only with manual range selection.
Manual Range Selection
16
MULTIMETER
OFF
600V
COM
CAT
+
To return to autoranging, press for
2 seconds, or change the measurement
mode.
ip15i.eps
Battery Saver
If the meter is ON but inactive and not connected to voltage for more than
45 minutes, the display goes blank to preserve battery life. To resume
operation, press any button.
Battery Saver is disabled in MIN/MAX record mode.
