Fluke 301D - Features and Controls Overview

3
301D/301E
Users Manual
Features/Controls
Table 1 is a list of features and controls.
Table 1. Feature/Control Descriptions
600A
V003
1
7
6
3
2
5
8 9
4
Item Description
1
Jaw
2
Tactile Barrier
3
Hold
4
Control Knob
5
Display
6
Extends the function selection to yellow items on the control knob. Push >2 s to turn on/
turn o󰀨 the backlight.
7
Trigger
8
COM terminal
9
Volts/Ohm input terminal
