Fluke 324 Calibration Manual

Clamp Meter
Calibration Adjustment
17
Table 5. Calibration Adjustment
Test
(Switch Position)
LCD Reading Calibrator Output
323
AC Volts
C-1.1 1.05 V, 50 Hz
C-1.2 40 V, 50 Hz
C-1.3 10 V, 50 Hz
C-1.4 300 V, 50 Hz
DC Volts C-2.2 400 V
Ohms
C-3.1 400 Ω
C-3.2 4000 Ω
AC Amps
(with 50-Turn Coil)
C-4.1 0.019 A, 50 Hz
C-4.2 0.42 A, 50 Hz
C-4.3 1.026 A, 50 Hz
C-4.4 6 A, 50 Hz
[1]
324 and 325
Temperature
C-21 0 V
C-22 0.02 V
C-23 0.02 V
AC Volts
C-00 600 V, 50 Hz
C-01 600 V, 100 Hz
C-02 600 V, 200 Hz
C-03 600 V, 300 Hz
C-04 600 V, 400 Hz
DC Volts
C-05 0 V
C-06 600 V
C-07 0 V
C-08 0.5 V
Ohms
C-09 0 Ω
C-10 400 Ω
C-11 440 Ω
C-12 4000 Ω
C-13 (325 only) 4400 Ω
C-14 (325 only) 40000 Ω
[1] At each function, after all calibration points is adjusted, the display shows “Save” after the last
calibration point. Push HOLD to save the calibration data.

Fluke 324 Specifications

General

AC voltage	600 V
Continuity	30 Ω
Resistance (max)	4000 Ω
Resistance (min)	400 Ω
Measuring category	CAT III 600V, CAT IV 300V
AC current maximum resolution (probe)	400 A
Product color	Black, Red, Yellow
Test leads	Yes

Weight and Dimensions

Depth	34 mm
Width	75 mm
Height	207 mm
Weight	208 g
