Fluke 324 Calibration Manual

323/324/325
Calibration Manual
18
Table 8. Calibration Adjustment (cont.)
Test
(Switch Position)
LCD Reading Calibrator Output
324 and 325
Capacitance
C-15 0.1 μF
C-16 0.5 μF
C-17 1.5 μF
C-18 110 μF
C-19 500 μF
C-20 1000 μF
324
AC Amps
(with 50-Turn Coil)
C-24 0.8 A, 50 Hz
C-25 0.8 A, 100 Hz
C-26 0.8 A, 200 Hz
C-27 0.8 A, 300 Hz
C-28 0.8 A, 400 Hz
C-29 8 A,50 Hz
325
AC Amps
(with 50-Turn Coil)
C-24 0 A
C-25 0.02 A, 50 Hz
C-26 0.8 A, 50 Hz
C-27 0.8 A, 100 Hz
C-28 0.8 A, 200 Hz
C-29 0.8 A, 300 Hz
C-30 0.8 A, 400 Hz
C-31 8 A, 50 Hz
DC Amps
(with 50-Turn Coil)
C-32 0 A
C-33 0.02 A
C-34 0.8 A
C-35 0.88 A
C-36 8 A

Fluke 324 Specifications

General

AC voltage	600 V
Continuity	30 Ω
Resistance (max)	4000 Ω
Resistance (min)	400 Ω
Measuring category	CAT III 600V, CAT IV 300V
AC current maximum resolution (probe)	400 A
Product color	Black, Red, Yellow
Test leads	Yes

Weight and Dimensions

Depth	34 mm
Width	75 mm
Height	207 mm
Weight	208 g
