414D/419D/424D
Users Manual
14
Z
X
Y
180°
180°
180°
8
gwo22.eps
Magnetic Declination
The difference between the north geographic pole and
the north magnetic pole is known as magnetic declination,
or more plainly, declination. The angle of declination is
different at different locations on the earth. The
geographic and magnetic poles are aligned so declination
is minimal. From some locations, the angle between the
two poles can be fairly large.
Table 4 is a list of the current angles of declination by
location. For other declination values, contact your local
Geomagnetic Institute.
To set the Meter with the correct compensation for your
location:
1. Push
at the same time.
The display shows and the current setting. The
default value is 0 °.
2. Push
and to change the value.
3. Push to accept the new value.
