Features of Fluke 434-II/435-II/437-II
Logging of Measuring Values in Meter Screens 3
3-3
Logging of Measuring Values in Meter Screens
All measuring values in a Meter screen are logged. The average, minimun and maximum
values are logged with an adjustable average time (default value: 1 s) during the time that
the measurement is running. The average time is adjustable via the key sequence SETUP,
F4 – MANUAL SETUP, F3 – FUNCTION PREF. Use the arrow keys to select the
desired Average time. Also the total duration of the measurement and the start delay are
adjustable.
When the measurement is stopped by operation of function key F5 – HOLD the logged
data is saved on SD-card as Measurement xx. The measurement data is available via the
MEMORY key and function key F1 – RECALL DELETE. Next use the up/down arrow
keys to select the desired measurement and open it with function key F5 - RECALL. The
logged values are visible under F3 – TREND. Cursor and Zoom can be used to zoom in
on signal details.
If you resume the measurement via key sequence F5 – RUN, F3 – TIMED you enter a
menu that allows you to adjust average time, duration and start moment for that particular
measurement.
Note: under the LOGGER key you can log a maximum of 150 readings. The set or
reading to be logged is user definable. Refer to Chapter 21 for more information.
