Introduction
The Motor Analyzer is a feature that measures mechanical power, torque, and rpm on direct-on-line
asynchronous motors or asynchronous motors driven by a variable speed drive (VSD). It is a standard
feature on the Fluke 438-II and available as an optional upgrade for all models in the Fluke 430 Series II
(Fluke 430-II/MA Motor Analyzer upgrade). Combined with electrical power and power-quality
measurements, the Motor Analyzer feature provides useful information about a motor’s mechanical and
electrical operational variables and its efficiency.
The feature dynamically measures critical motor variables as the process operates with no need to use
additional mechanical sensors or shut down the process.
The Motor Analyzer is for three wire, three-phase DELTA measurement configurations. If any other
configuration is active, the feature prompts you to go to the SETUP menu to specify a supported
configuration:
• 3-phase Delta
• 3-phase Open Leg
• 3-phase IT
• 2-Element
How to Contact Fluke
To contact Fluke, call one of the following telephone numbers:
• Technical Support USA: 1-800-44-FLUKE (1-800-443-5853)
• Calibration/Repair USA: 1-888-99-FLUKE (1-888-993-5853)
• Canada: 1-800-36-FLUKE (1-800-363-5853)
• Europe: +31 402-675-200
• Japan: +81-3-6714-3114
• Singapore: +65-6799-5566
• Anywhere in the world: +1-425-446-5500
Or, visit Fluke's website at www.fluke.com
.
To register your product, visit http://register.fluke.com
.
To view, print, or download the latest manual supplement, visit http://us.fluke.com/usen/support/manuals
.
