438-II
Users Manual
2
Safety Information
A Warning identifies hazardous conditions and procedures that are dangerous to the user. A Caution
identifies conditions and procedures that can cause damage to the Product or the equipment under test.
XW Warning
To prevent possible electrical shock, fire, or personal injury:
•
Read all safety information before you use the Product.
•
Use the Product only as specified, or the protection supplied by the Product can
be compromised.
•
Comply with local and national safety codes. Use personal protective
equipment (approved rubber gloves, face protection, and flame-resistant
clothes) to prevent shock and arc blast injury where hazardous live conductors
are exposed.
•
Do not use the Product if it is damaged.
•
Disable the Product if it is damaged.
•
Do not work alone.
See the 434-II/435-II/437-II Users Manual for a complete list of Safety Warnings and explanation of Symbols
used on the Product.
In The Box
The Motor Analyzer Kit includes:
• 438 Series II Power Quality and Motor Analyzer (Side Strap, Battery Pack BP290 -28 Wh, and 8 GB SD
Wireless SD Memory Card installed)
• Decals for Input Sockets (EU & UK, EU, China, UK, US, Canada)
• Hang Strap
• Alligator Clips (set of 5)
• Test Leads, 2.5 m + Color Coding Clips (set of 5)
• Power Adapter
• Regional Power Cord
• Safety Information (Multi-Language)
• CD-ROM with Manuals (Multi-Language), PowerLog Software, and USB drivers
• USB Interface Cable for PC Connection (USB A-to-mini USB B)
• Soft Carry Case C1740
Additional kits are available that include Flexible 6000 A AC Current Probes (set of 4). Contact Fluke for
more information about the kits that are available for the Motor Analyzer.
