5730A Sales and Demo Guide
Fluke Corporation Company Confidential Page 12 of 28
10.7. Wideband RF option
The 30 MHz Wideband option can be purchased to expand the AC Frequency and RF calibration
capability of the 5730A. The Wideband option increases the addressable workload of the calibrator.
Most customers interested in the Wideband option are the Military, Prime Contractors who work
with Military systems, and large 3
rd
Party Calibration labs that own Military contracts. Wideband
capability is activated through a button on the toolbar at the bottom of the touchscreen. When
active, the Visual Connection Management terminals illuminate the wideband connector.
11. Competitive comparison
Key specs/feature comparison
5700A 5720A 5730A
DC Voltage   
Range:
Best 1 Year, 95% Specification:
7 ppm + 3.5 µV 3.5 ppm + 2.5 µV 3.5 ppm + 2.5 µV
AC Voltage   
Best 1 Year, 95% Specification: 75 ppm + 6 µV 45 ppm + 8 µV 42 ppm + 8 µV
DC Current   
Best 1 Year, 95% Specification: 50 ppm + 8 nA 35 ppm + 7 nA 35 ppm + 7 nA
AC Current   
Best 1 Year, 95% Specification: 140 ppm + 16 nA 120 ppm + 8 nA 103 ppm + 8 nA
Resistance   
Range:
Best 1 Year, 95% Specification: 12 ppm 8.5 ppm 6.5 ppm
Wideband option   
Range:
Best 1 Year, 95% Specification:
±0.4% of setting ±0.4% of setting ±0.4% of setting
0 to ± 1100 V
220 mV to 1100 V
10 Hz to 1 MHz
Range:
Functionality
Range:
0 to ± 2.2 A
Fluke 5725A: 0 to ± 11 A
Fluke 52120A: 0 to ± 100 A
9 µA to 2.2 A, 10 Hz to 10 kHz
Fluke 5725A: 9 µA to 11 A
Fluke 52120A: 9 µA to 120 A
Range:
0 to 100 MΩ, 18 values in x1 and x1.9
300 µV to 3.5 V, 10 Hz to 30 MHz
