Fluke 5730A/03 Sales Guide

5730A Sales and Demo Guide
Fluke Corporation Company Confidential Page 4 of 28
4. Value Proposition
The new Model 5730A calibrator delivers the best accuracy and usability of any calibrator available
today. It’s unique combination of best in class performance and modern features will enhance your
labs workload coverage while also improving your cycle times and workflow efficiency. The 5730A
also simplifies operator training and reduces learning curves through the use of familiar 5700 type
keyboard/knob controls in combination with an up to date, significantly more informative touch
screen interface. All of these advances come together in the 5730A to save you time and money
while leveraging your existing procedure and programs through emulation of the industry standard
5700A and 5720A.
5. Features and Benefits
Feature
Benefit
Touchscreen GUI
Easy-to-use + simple status indication + flat menu navigation = Lower cost
of training for employees, quicker setup time, quicker manual operation.
Specifications
Up to 40% improvement in measurement uncertainties compared to
5720A. Improvements in AC voltage, AC current, and resistance.
LED lit Output (VCM
TM
terminals)
Provide customer guidance in proper cable connection minimizing risk of
in-proper connections, improves safety for user and instrument.
Updated digital internal
technology
Improved best-in-class accuracy with newer internal digital components
and technology offering better support for the future.
Artifact Calibration
Maintain better accuracy specifications for longer. This will allow you to
achieve 24 hour, 90 day, or 180 day specifications for up to 2 years, thus
addressing higher accuracy workload. Fluke Calibration recommends
performing a full verification check at a Fluke Service Center every 2 years.
Local language support
GUI is equipped with 9 language choices
52120A Compatible
Use your 52120A to boost current output to 100 A DC or 120 A AC in
closed loop operation. 5730A drives the 52120A and all outputs are
displayed directly on 5730A GUI.
5725A Compatible
Fully compatible with existing 5725A amplifiers, thus extending your
current and frequency coverage while protecting your investment.
MET/CAL Compatible
MET/CAL version 8.2 or newer required to use 5730A improved specs. Will
work with older versions of MET/CAL, but will need to identify itself as a
5700A or 5720A and will utilize those units’ spec tables.
MET/CAL Backward
Compatibility
“Device Mapping” capability allows 5730A to identify itself as a 5700A or
5720A to prevent MET/CAL users from having to edit existing procedures.
5730A is a drop-in replacement for existing 57XX calibrators, saving time
and cost.
USB port for flash drives
Allows simple collection of calibration constants (CSV format) onto a USB
stick for easy import to Excel for stability and drift analysis. Run Cal Check
and then download constants via the front panel USB port.
UUT error display
Allows user to quickly know the UUT % or ppm error.
4 Communication ports
IEEE-488 (GPIB), RS232, Ethernet, and USB allow remote control via a PC
Full-time Specification
Display
Based on calibrator settings for confidence (99% or 95%) and spec interval
(24 hr, 90 day, 180 day, 1 year), 5730A automatically displays the accuracy
specifications for every output range and function. Toggle ON and OFF.
